Stainless Steel Single Slotted/Grooved Tubes
O.D Slot/Channel Size Wall Thickness Suitable for Thickness of Glass
42.4 mm 20 X 20 mm 1.2 ~ 2.0 mm 8 ~ 15 mm
42.4 mm 24 X 24 mm 1.2 ~ 2.0 mm 8 ~ 15 mm
48.3 mm 27 X 30 mm 1.2 ~ 2.0 mm 8 ~ 15 mm
50.8 mm 15 X 15 mm 1.2 ~ 2.0 mm 8 ~ 12 mm
63.5 mm 20 X 20 mm 1.2 ~ 2.0 mm 8 ~ 15 mm
76.2 mm 25 X 25 mm 1.2 ~ 2.0 mm 8 ~ 22 mm

Note:
The outside diameters and widths listed above are reality availables.For more information,please contact our sales representatives.
Surface trement: Not polished or polished with Finsh #320 and #600.Other special surface please contact to our sales.

Stainless Steel Double Slotted/ Grooved Tubes (90/180 deg)
O.D Slot/Channel Size Wall Thickness Suitable for Thickness of Glass
50.8 mm 15 X 15 mm 1.2 ~ 2.0 mm 8 ~ 15 mm

>Note:
The outside diameters and widths listed above are reality availables.For more information,please contact our sales representatives.
Surface trement: Not polished or polished with Finsh #320 and #600.Other special surface please contact to our sales.
