- MECHANICAL AND STRUCTURAL STAINLESS STEEL TUBES
- STAINLESS STEEL SQUARE TUBE
- STAINLESS STEEL RECTANGULAR TUBE
- INDUSTRIAL STAINLESS STEEL PIPES
- STAINLESS STEEL SANITARY TUBE
- LIGHT GAUGE STAINLESS STEEL PIPE FOR ORDINARY PIPING
- STAINLESS STEEL SINGLE/DOUBLE SLOTTED/GROOVED TUBES
- STAINLESS STEEL OVAL/HALF ROUND D TUBES
- STAINLESS STEEL OVAL SINGLE SLOTTED/ GROOVED TUBES
- TABLE OF TOLERANCE
TABLE OF THE CHEMICAL OMPOSITION OF STAINLESS STEEL PIPES AND TUBES
Specification |
Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | ||
JIS | SUS 304 | 0.08 | 1.00 | 2.00 | 0.04 | 0.03 | 8.00~11.00 | 18.00~20.00 | |
SUS 304L | 0.03 | 1.00 | 2.00 | 0.04 | 0.03 | 9.00~13.00 | 18.00~20.00 | ||
SUS 316 | 0.08 | 1.00 | 2.00 | 0.04 | 0.03 | 10.00~14.00 | 16.00~18.00 | 2.00~3.00 | |
SUS 316L | 0.03 | 1.00 | 2.00 | 0.04 | 0.03 | 12.00~16.00 | 16.00~18.00 | 2.00~3.00 | |
ASTM | TP304 | 0.08 | 0.75 | 2.00 | 0.04 | 0.03 | 8.00~11.00 | 18.00~20.00 | |
TP 304L | 0.035 | 0.75 | 2.00 | 0.04 | 0.03 | 8.00~13.00 | 18.00~20.00 | ||
TP 316 | 0.08 | 0.75 | 2.00 | 0.04 | 0.03 | 11.00~14.00 | 16.00~18.00 | 2.00~3.00 | |
TP 316L | 0.035 | 0.75 | 2.00 | 0.04 | 0.03 | 10.00~15.00 | 16.00~18.00 | 2.00~3.00 |
JIS | ASTM | CNS | |||
Type |
() Annealing Process |
Type |
() Annealing Process |
Type |
() Annealing Process |
SUS 304 | 1010 WATER QUENCHING |
TP 304 | 1040 WATER QUENCHING |
TP 304 | 1010 WATER QUENCHING |
SUS 304L | TP 304L | TP 304L | |||
SUS 316 | TP 316 | TP 316 | |||
SUS 316L | TP 316L | TP 316L |
Type | Density(g/cm3) | Calculation Formula |
SUS 304 SUS 304L TP 304 TP 304L |
7.93 | W=0.02491 tD-t |
SUS 316 SUS 316L TP 316 TP 316L |
7.98 | W=0.02507 tD-t |
- W: Weight(kg/m)
- D: Outside Diameter(mm)
- t: Wall Thickness(mm)
CNS G3124 ASTM A312 JIS G3459
Item Specification |
Outside Diameter | Wall Thickness | Length | ||||||||||
CNS G3124 JIS G3459 |
|
2mm 0.2mm |
Should not be shorter than appinted lengths |
||||||||||
ASTM A312 | O.D.[mm] |
48.26 | 48.26 114.3 |
114.3 219.08 |
219.08 457.2 |
12.5% |
|
||||||
[mm] Tolerance |
+0.4 -0.4 |
0.8 | +1.6 -0.8 |
+2.4 -0.8 |
CNS G3119 JIS G3446
Item Specification |
Outside Diameter | Wall Thickness | Round ness | Straightness | Length |
CNS G3119 JIS G3446 |
50mm 0.5mm 50mm 1% |
3mm 0.3mm 3mm 10% |
10mm/6M | Definite Cut Lengths +50mm -0mm |
Item Specification |
Outside Diameter (mm) |
Wall Thickness (mm) |
Outside Diameter tolerance(mm) |
Wall Thickness (mm) |
Length (mm) |
ASTM A554 | under 12.7 | 0.51 to 1.24 | 0.10 | 10% Wall Thickness tolerance 10% of nominal wall Thickness |
Definite Cut Lengths |
12.7 to 25.4[incl] | 0.51 to 1.65 Over 1.65 to 3.40 |
0.13 0.25 |
|||
Over 25.4 to 38.1[incl] | 0.64 to 1.65 Over 1.65 to 3.40 |
0.20 0.25 |
|||
Over 38.1 to 50.8[incl] | 0.64 to 1.24 Over 1.24 to 2.11 Over 2.11 to 3.78 |
0.25 0.28 0.30 |
|||
Over 50.8 to 63.5[incl] | 0.81 to 1.65 Over 1.65 to 2.77 Over 2.77 to 4.19 |
0.30 0.33 0.36 |
|||
Over 63.5 to 88.9[incl] | 0.81 to 4.19 | 0.36 | |||
Over 88.9 to 127.0 [incl] | 0.89 to 4.19 | 0.51 |
ASTM A554
Item Specification |
Outside Diameter | Wall Thickness | Digonal | Eduge radius | Straightness | Length | Other |
Rectangular tubes Square tubes |
31.8mm 0.38 31.8~63.5mm 0.51 63.5mm 0.76 |
10% | 0.4mm | 2.5m/MR | 10mm/6M | +50mm -0 |
Flatness 0.15mm |
JIS G3448
Item Specification |
Outside Diameter | Wall Thickness | Length | ||||||||||
JIS G3448 |
|
|
Definite Cut Lengths | ||||||||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
|
|||||||||||||
|
CNS G3131JIS G3447ASTM A269ASTM A270
Item Specification |
Outside Diameter | Wall Thickness | Length | ||||
CNS G3131 JIS G3447 |
|
10% | -0mm +10mm |
||||
|
|||||||
|
|||||||
|
|||||||
|
|||||||
|
|||||||
|
|||||||
|
|||||||
ASTM
A269 ASTM A270 |
|
OD 12.7mm15% OD12.7mm10% |
|
||||
|
|||||||
|
|||||||
|
Specification | Mechanical Properties | Characteristics | |||||
Tenside Strength | Elogation | Yied Strength | Hardness | ||||
kgf/mm2 [N/mm2 ] |
% | kgf/mm2 [N/mm2 ] |
HRB | ||||
JIS ASTM |
SUS 340 TP 340 |
53 [520] |
35 | 21 [205] |
90 | 304 | Resistant to highly oxidizing acids such as nitric acid, geeral corrosion-resistant and heat resistant |
SUS 340L TP 340L |
49 [480] |
35 | 18 [175] |
90 | 304L | Resistant to various organic acids such as diluted sulfuric acid, sulfurous acid and acetic acid, anit-pitting corrosion. |
|
SUS 316 TP 316 |
53 [520] |
35 | 21 [205] |
90 | 316 | 304+inter-granular corrosion resistance. |
|
SUS 316L TP 316L |
49 [480] |
35 | 18 [175] |
90 | 316L | 306+inter-granular corrosion resistance, heat resistance up to 650. |
